ARC EDGE

Resilient, interoperable communications so
you can stay connected. Anywhere. In any condition.
Book A Demo
Built for the moment when connectivity determines
the outcome. Arc Edge keeps teams connected,
aligned, and moving forward when the environment
turns hostile, remote, or uncertain.
Main features
Deploy in <120s
Multipath Comms
256 Bit Encrypted
Field-Ready Power​
Mesh networking
Real-time awareness
Main features
RAPID DEPLOY
MULTIPATH COMMS
256 Bit Encrypted
Field-Ready Power
Mesh Networking
Real Time Awareness
ARC EDGE
For the teams who don’t
have the option to disconnect.
Always-On Connectivity
Always-On Connectivity

ARC Edge fuses Dual-SIM LTE, satellite broadband, and Wi-Fi-as-WAN into a single, unstoppable network with SD-WAN routing and automatic failover. It hunts for the strongest signal in real time and uses Dynamic Multipath Optimization (DMPO) to keep traffic moving with near-zero disruption, so your team stays online no matter what.

Situational Awareness
Situational Awareness

ARC Edge unifies live team tracking, shared mapping, drone video, and sensor fusion into a single real-time operational picture through the AGIS platform. Every operator sees the same data instantly, delivering synchronized awareness and always-on operational cohesion in the field.

Edge Compute + Mesh
Edge Compute + Mesh

ARC Edge combines on-device processing, mesh networking, drone relay integration, and a local mission server into a fully distributed edge architecture. Infrastructure moves with the team, delivering always-on resilient operations without dependence on fixed networks.

Secure Video + Voice
Secure Video + Voice

ARC Edge delivers TEV encrypted conferencing with support for direct video, full duplex communication, group calls, and one-to-one push-to-talk. End-to-end AES 128/256-bit VPN with PQC-ready encryption ensures always-on, resilient and secure communications across every mission profile.

950 Mbps
SD-WAN throughput up to 950 Mbps
REDUNDANT POWER
~379 Wh total capacity with 100W PD charging support
MULTIPATH COMMUNICATION
8-port Gigabit Layer 2 switching for local devices
BUILT FOR THE EDGE
Rugged, portable form factor backpack
technical specifications ///
ARC-EDGE WAN Core

• Form Factor: Desktop / wall / rack-mountable
• Dimensions: 8.11" × 7.07" × 1.38" (206 × 179.5 × 35 mm)
• Weight: 2 lb (0.9 kg)
• Ports: 4 × 1G RJ45 (LAN/WAN), 1 × 1G SFP, 1 × USB 3.0 (for cellular)
• Performance: Max throughput 950 Mbps, supports up to 225,000 concurrent flows
• Power: 15W typical / 20W max; external AC adapter (100–240V)
• Networking Features: Dynamic Multipath Optimization (DMPO), IPsec, firewall, QoS, BGP/OSPF, zero-touch provisioning
• SFP Support (included with kit): SFP fiber LC (1000BASE-SX/LX compatible), SFP copper (1000BASE-T RJ45 transceiver)
• Additional: Wi-Fi 6 capable (710-W variant) or 5G-ready options available

8-Port Layer 2 Smart Gigabit Switch (LGS308)

• Ports: 8 × Gigabit Ethernet RJ45
• Switching Capacity: 16 Gbps; forwarding rate 11.90 Mpps
• Layer 2 Features: VLAN, QoS, Link Aggregation (LACP), IGMP snooping, port mirroring
• Dimensions: 8.27" × 4.09" × 0.98" (210 × 104 × 25 mm)
• Power: ~8W (100–240V AC)
• Form Factor: Compact desktop

100PD Power Banks

• Capacity: 94.7 Wh (14.8V, 6400 mAh) per unit → Total system capacity: ~379 Wh
• Ports (per unit): USB-C PD (100W output / 60W input), 2 × USB-A (12W), 15W wireless charging pad
• Dimensions (per unit): 7.69" × 3.81" × 1.02" (19.53 × 9.68 × 2.59 cm)
• Weight (per unit): 1.5 lb (0.68 kg) → Total: 6 lb (2.72 kg)
• Features: Simultaneous charge/discharge, TSA-approved, Li-ion cells
• Runtime Estimate: Powers full ARC-EDGE kit (SD-WAN + switch + MPU5) for 8–12+ hours depending on load (actual varies with traffic/radio use)

 Associated Cabling & Accessories (Included)

• ARC-EDGE WAN Core: 1 × SFP fiber transceiver with LC connector (multi-mode or single-mode as specified), 1 × SFP copper (RJ45) transceiver
• Networking Cables: Multiple Cat6 Ethernet cables (various lengths) for SD-WAN ↔ Switch ↔ MPU5 ↔ PC/laptop
• Power & Charging: USB-C PD cables (100W-rated) for charging/powering ARC-EDGE WAN Core, switch, and MPU5 from rechargeable battery units, Battery recharge system with charging cables and wall adapters, Inter-battery linking cables for parallel/series power management
• PC/Laptop Integration: Ethernet cable + USB-to-Ethernet adapter options for direct connection
• Miscellaneous: Cable management straps, spare SFP dust caps, quick-connect power distribution harness

ARC Edge Overall System

Packed Dimensions (approx.): Tactical Deployment Pack: 22" H × 14" W × 10" D; Pelican Case: 24" H × 18" W × 12" D.
‍Total Weight: including Starlink Mini 30~35 lbs / 13.6~15.9 Kg
‍Power Autonomy: 6–12+ hours (≈379 Wh total from 4× batteries); expandable with solar.
‍Deployment Time: <10 minutes.
‍Operating Temperature: –30°C to +50°C (component-dependent; MPU-5 to +85°C).
‍Ingress Protection: IP65/IP68 on key components.
‍Throughput & Performance SD-WAN: Up to 950 Mbps (1300B packets).MANET: 100+ Mbps, self-forming/healing mesh. Aggregate: Up to 2 Gbps (multi-transport).
‍Power System 4×100PD batteries (94.7 Wh each → 379 Wh total).100W USB-C PD output per unit.

Final Notes

• ARC-EDGE is a custom integration communication system. All components are commercial-off-the-shelf (COTS) but pre-configured and cabled for seamless operation.
• Custom firmware/profiles or additional accessories (e.g., solar panels, antennas) available upon request.
• For exact runtime, throughput, or radio frequency details, consult deployment-specific configuration.
‍
This specifications sheet provides a complete reference for the ARC-EDGE system. Contact for customizations, diagrams, or deployment guides.
